Firmware Download

UART Firmware Download​

  1. Click the download link below to get the firmware:

    • You can obtain the firmware via the following links:
    • The firmware location is at:
    FLY-Firmware/Screen/Wiscreen/Wiscreen-7/UART

  2. Download interface reference:

    Loading...

WiFi Firmware Download​

  1. Click the download link below to get the firmware:

    • You can obtain the firmware via the following links:
    • The firmware location is at:
    FLY-Firmware/Screen/Wiscreen/Wiscreen-7/WIFI

  2. Download interface reference:

    Loading...
    Loading...

Firmware Update Steps​

Step 1: Prepare the Firmware File​

  1. Rename the downloaded firmware file to:

    update.img

  2. Important Notes:

    • If using a TF card/USB drive, ensure the storage device:
      • Has only one partition
      • Is formatted with the FAT32 file system

Step 2: Transfer the Firmware File​

  1. Copy the renamed update.img file to the root directory of the TF card or USB drive
  2. Insert the storage device into the screen (hot-plug is supported; it can be inserted while the screen is powered on)

Step 3: Perform the Upgrade Operation​

  1. Check the corresponding option on the screen interface
  2. Click the "Upgrade" button to start the upgrade
  3. Wait for the upgrade to complete; the screen will automatically restart
